ASENWARE AW-D101 Addressable Smoke Detector

The ASENWARE AW-D101 Addressable Smoke Detector is an intelligent fire detection device designed to identify smoke during the early stages of a developing fire. It connects to a compatible addressable fire alarm control panel, allowing the system to monitor the detector continuously and identify its precise programmed location whenever an alarm or fault occurs.

Unlike conventional detectors that generally identify only an affected zone, each AW-D101 detector can be assigned a unique address. This helps security teams, building managers and emergency responders determine the specific room, floor or area where smoke has been detected. The detector is designed for use with the ASENWARE AW-FP100 Series Addressable Fire Alarm Control Panel.

Primary Function

The detector is designed to:

• Continuously monitor the surrounding environment for smoke
• Detect smoke produced during the early stages of a fire
• Send an individually addressed alarm signal to the control panel
• Help identify the exact detector and programmed location in alarm
• Provide visible normal and alarm status indication
• Support remote testing from the compatible control panel
• Operate as part of a complete addressable fire alarm system

How the Addressable Smoke Detector Works

During normal operation, the detector continuously communicates with the fire alarm control panel through the addressable loop.

When smoke enters the detector and reaches its alarm threshold:

1. The detector identifies the smoke condition.
2. It sends its unique address and alarm status to the control panel.
3. The control panel displays the detector’s programmed location.
4. The detector’s red LED indicators remain illuminated.
5. The fire alarm panel activates the programmed warning and control functions.

Under normal conditions, the detector’s two red LEDs blink periodically. During a confirmed alarm condition, the indicators remain steadily illuminated until the system has been investigated and reset.

Key Product Features

• Intelligent addressable smoke detection
• Unique device addressing for accurate location identification
• Addressable analogue communication
• Two-wire loop connection
• Low standby power consumption
• Two red LED status indicators
• LEDs blink during normal monitoring
• LEDs remain illuminated during an alarm
• Remote testing from the fire alarm control panel
• Connection support for an optional remote indicator
• Compact ceiling-mounted design
• Separate mounting base for easier installation and servicing
• Suitable for medium and large addressable fire alarm systems
• Compatible with the ASENWARE AW-FP100 Series control panel
• White housing suitable for most interior ceilings

Product Specifications

• Brand: ASENWARE
• Model: AW-D101
• Product Type: Addressable smoke detector
• System Type: Intelligent addressable fire alarm system
• Operating Voltage: 18V to 28V DC
• Normal Operating Current: Maximum 2.5mA
• Alarm Current: Maximum 3mA
• Smoke Sensitivity: Approximately 0.10 to 0.15dB/m
• Operating Temperature: Approximately -10°C to 50°C
• Communication: Addressable analogue
• Wiring Method: Two-wire loop connection
• Status Indicators: Two red LEDs
• Remote Indicator Connection: Supported
• Remote Panel Testing: Supported
• Approximate Diameter: 99.8mm
• Installation Type: Ceiling-mounted
• Colour: White
• Compatible Control Panel: ASENWARE AW-FP100 Series

These specifications are based on the manufacturer’s published information for the AW-D101 detector. The model number on the rear product label should be confirmed before the final specifications are published on the website.

Recommended Applications

The ASENWARE AW-D101 Addressable Smoke Detector is suitable for:

• Hotels, lodges and guesthouses
• Office buildings
• Apartment buildings
• Shopping centres and retail stores
• Schools, colleges and universities
• Hospitals and healthcare facilities
• Banks and financial institutions
• Warehouses and storerooms
• Factories and manufacturing facilities
• Server rooms and data centres
• Airports and transport terminals
• Government and public buildings
• Restaurants and hospitality facilities
• Commercial complexes
• Large residential developments

Suitable Installation Areas

Depending on the approved fire alarm design, the detector may be installed in:

• Bedrooms and hotel guest rooms
• Offices and meeting rooms
• Corridors and hallways
• Reception areas
• Classrooms
• Hospital rooms
• Retail spaces
• Storerooms
• Electrical and communication rooms
• Server facilities
• Public waiting areas
• General indoor working areas

Smoke detectors should not automatically be installed in locations containing heavy dust, steam, cooking fumes or normal airborne particles that may cause unwanted alarms. A heat detector or another suitable detection device may be more appropriate for such environments.

Installation and Commissioning

The detector should be installed, addressed, programmed and tested by a qualified fire alarm technician. Its position and spacing should follow the approved fire alarm design, manufacturer instructions and applicable fire safety requirements.

Professional installation should include:

• Confirming compatibility with the control panel
• Installing the correct detector mounting base
• Connecting the device to the addressable loop
• Assigning a unique detector address
• Programming an accurate location description
• Confirming normal communication with the control panel
• Testing the detector’s alarm response
• Checking the LED indicators
• Testing any connected remote indicator
• Confirming activation of the required alarm outputs
• Recording the detector in the system documentation

The detector must not be painted, covered or positioned where furniture, ceiling decorations, ventilation equipment or other objects may obstruct smoke entry.

Inspection and Maintenance

Regular inspection and testing are necessary to keep the detector operational. Routine maintenance should include:

• Confirming that the detector remains securely mounted
• Checking the housing for cracks or physical damage
• Inspecting the smoke-entry openings for obstruction
• Removing dust using approved cleaning procedures
• Confirming that the LED indicators operate correctly
• Testing communication with the fire alarm panel
• Conducting an approved functional smoke-detector test
• Confirming that the correct address appears on the panel
• Checking the programmed room or location description
• Reviewing any detector fault messages
• Recording inspection and testing results
• Replacing damaged or unreliable detectors

Testing should be completed using approved smoke-detector testing equipment. Open flames, cigarettes or uncontrolled smoke sources should not be used to test the detector.

Important Product Note

The AW-D101 is a system-connected addressable smoke detector, not a standalone battery-operated smoke alarm. It requires a compatible addressable fire alarm control panel, correct loop wiring, device addressing, programming and professional commissioning.

It detects smoke but does not extinguish a fire or independently provide a complete building evacuation warning. A complete fire alarm system may also require manual call points, heat detectors, alarm sounders, visual alarm devices, interface modules, backup power supplies and other system components.
